Foam chamber extinguishes fires and/or inhibits vapor diffusion in the gentlest way by covering the surface of a flammable liquid ignition source with foamed foam. It is internally equipped with a vapor sealing element (non-glass material) that actively ruptures when the pressure reaches the design pressure, providing daily isolation from toxic and harmful gases such as tank vapors and enabling rapid response in emergencies.

The tank's inner wall is fitted with bafles to redirect the foam towards the tank wall. The foam flows down the tank wall to the liquid surface, effectively reducing immersion depth and fuel leakage, thereby maximizing the foam's fire extinguishing effectiveness.

It is the preferred protective device for large open-air storage tanks of flammable liquids, with typical applications including manufacturing plants, large tank farms, oil refineries, and chemical plants.

Advantages: Stable rupture pressure of sealing elements, good foaming effect, and no internal wateraccumulation.

Model	PCL8(UIND-8)	PCL24(UIND-24)	PCL48(UIND-48)	PCL64(UIND-64)
Pressure	100PSI(7BAR)
Flow Rate	8L/S	24L/S	48L/S	64L/S
Inlet Flange Size	2"	3"	4"	6"
Outlet Flange Size	4"	6"	8"	10"
Body Material	Stainless Steel/ Steel
Nozzle Material	Stainless Steel
Installationdirection	Vertical
Vapor Seal burstpressure	10PSI-25PSI (0.7-1.72BAR)
Connection	Flanged

MODEL	PCL8 (UIND-8)	PCL24 (UIND-24)	PCL48 (UIND-48)	PCL64 (UIND-64)
A (mm)	900	1055	1200	1400
B (mm)	500	590	650	760
C (mm)	200	250	300	355
